Product Parameters
|
Nominal Voltage
|
25.65V
|
51.3V | 51.3V |
|
Nominal Capacity
|
160Ah
|
160Ah | 320Ah |
|
Cycle Life
|
≥4000 times
|
≥4000 times | ≥4000 times |
|
Max.Charging Voltage
|
31V
|
62V | 62V |
|
Standard Charging Current
|
80A
|
80A | 160A |
|
Max Charging Current
|
160A
|
160A | 200A |
|
Max Discharge Current
|
160A
|
160A | 200A |
|
Peak Discharge Current
|
≤300A(3s)
|
≤300A(3s) | ≤400A(3s) |
|
Discharge cut-off Voltage
|
18V
|
27V | 27V |
|
Charging cut-off Voltage
|
31V
|
62V | 62V |
|
Communication Interface
|
Optional
|
||
|
OEM/ODM
|
Accepatable
|
||
|
Operating Temperature(℃)
|
Charge:-10~+55ºC ; Discharge: -40~+65ºC
22222 |
||
|
Certification
|
CE,UN38.3, MSDS, ROHS, IEC, ISO9001
|
||
|
Storage Temperature
|
Short-term storage:-20~+45 ºC(<3 month); long-term stroage:-10 ~+40 ºC(<6 month)
|
||
|
Storage Humidity
|
45-75%RH
|
||
Features
1.High Safety: Excellent thermal stability & lower thermal runaway risk. Optional fire suppression module for enhanced safety.
2.Excellent Low-Temperature Performance:Reliable discharge at -20°C; basic output maintained at -40°C. Ideal for cold storage & cold climates.
3.Long Cycle Life: 6,000+ cycles with deep cycling. Reduces battery replacement frequency and total cost of ownership.
4.Optimized Forklift Counterweight: Higher weight than LiFePO4 batteries at the same capacity. Can replace part of the metal counterweight for improved stability.
5.Easy Lead-Acid Replacement: Highly compatible with existing lead-acid battery specifications and mounting dimensions. Direct replacement with no forklift modification.
Explore our comprehensive factory capabilities and customized solutions
Applications
Home Energy Storage,Electric Forklift,RV,Automotive Start-Stop Power Supply,Electric Tricycle,Electric Motorcycle,etc.
FAQ
A：Yes, standard 48V communication protocol matches mainstream solar inverters. Same installation dimension, plug and play without modifying household circuit or inverter
A：Total capacity: 48×200=9600Wh (9.6kWh). Enough to power fridge, lighting, TV and small home appliances for 1 full day for regular family during blackout.
A: Yes, it supports parallel expansion flexibly. Adopt standard rack communication protocol, up to 16 units in parallel at most. Single unit energy: 48×200=9.6kWh, max total capacity reach 153.6kWh, fit household energy storage, communication base station and small commercial backup power.
A：Work stably from -40℃~+65℃, ≥85% capacity at -20℃; 3000~6000 charge cycles, normal service life over 10 years for daily solar storage.
A：Sodium ion supports 0V full deep discharge recovery. Even fully drained for weeks due to rainy no-sun weather, battery can be fully restored after recharging without permanent damage.
A:Sample orders start at 1 set, with small batches of 50 sets and large batches of 500 sets or more. We understand the needs of partners of all sizes.
