Product Parameters
|
Model |
12V 100Ah |
12V 200Ah |
24V 200Ah |
|
Rated Voltage |
12V |
24V |
|
|
Nominal Capacity |
100Ah |
200Ah |
200Ah |
|
Energy |
1200Wh |
2400Wh |
4800Wh |
|
Size(mm) |
330*173*220 |
385*204*272 |
520*269*220 |
|
Weight |
14Kg |
20Kg |
38Kg |
|
BMS Protection Function |
Over charge protection, Over discharge protection, Temperature protection, Balanced function |
||
|
Operating voltage range |
8V-15.8V |
8V-16V |
16V-32V |
|
Max. Continuous Charging Current |
100A |
200A |
200A |
|
Max. Continuous Discharging Current |
100A |
200A |
200A |
|
Peak Discharge Current |
200A（3S) |
400A（3S) |
400A（3S） |
|
Charge Temperature |
-18-60℃ |
||
|
Discharge Temperature |
-35-65℃ |
||
|
Storage Temperature |
Optimal long-term storage temperature |
||
|
-10°C ~30℃ |
|||
|
Waterproof Level |
IP65/IP67 |
||
|
Optional |
Bluetooth/Advanced Screen |
||
Features
1. Universal Voltage & Plug-and-play: Standard 12V/24V size & terminal same as lead-acid batteries, directly replace AGM/gel battery ; 24V design reduces line loss for medium off-grid solar system.
2. Wide Temperature Adaptation: Operate steadily from -35℃ to +65℃, ≥88% capacity retained at -20℃, perfect for cold-region & high-temperature outdoor energy storage.
3. Custom Discharge for Storage: Continuous discharge 1C, 3s short pulse 3C~5C , handle instant surge load of water pump & UPS backup power.
4. Zero-volt Deep Discharge Tolerance: Recoverable after full drain to 0V for 6 months, no permanent damage under irregular off-grid power shortage.
5. Built-in BMS Protection: Integrated battery management prevents overcharge/over-discharge/short circuit, low self-discharge
Explore our comprehensive factory capabilities and customized solutions
Applications
1.Off-grid Solar Energy Storage
2.RV & Marine Power Supply
3.UPS & Standby Backup Power
4.Outdoor Portable & Agricultural Equipment
FAQ
A： Yes. Standard size and reserved terminals support plug-and-play, perfectly replacing traditional 12V 24V lead-acid batteries for RV, energy storage and electric tricycles without any modification.
A： It features excellent low-temperature performance, strong instantaneous high-current output and longer cycle life. It solves the common defects of lithium and lead-acid batteries, with low after-sales rate and outstanding long-term cost performance.
A： It supports stable high-rate discharge and strong 3S peak current output. The voltage stays stable instantly, easily driving high-power loads like inverters, RV air conditioners and motors for heavy-load operation.
A:It has ultra-wide temperature adaptability. Working temperature: -40℃~65℃ (retains over 80% capacity at low temperature); Storage temperature: -30℃~60℃, suitable for all-season outdoor and RV scenarios.
A Completely safe. Built-in full-protection BMS prevents overcharge, overdischarge, overcurrent, short circuit and overheating. Sodium-ion material avoids thermal runaway risks, non-flammable and explosion-proof, ideal for long-term enclosed space power supply.
A:We provide a complete set of certified scanned copies and test report summaries, with UN 38.3 test reports and MSDS documents included for each batch.
A:Sample orders start at 1 set, with small batches of 50 sets and large batches of 500 sets or more. We understand the needs of partners of all sizes.
