Product Parameters
|
Model |
36V 105Ah |
51.2V 105Ah |
51.2V 100Ah | 51.2V 106Ah |
| Rated Voltage |
38.4V |
51.2V |
51.2V | 51.2V |
|
Nominal Capacity |
105Ah |
105Ah |
100Ah | 106Ah |
| Energy | 4.032KWh | 5.376KWh | 5.12kWh | 5.427kWh |
| Size(mm) | 436x350x270 | 510 x350x270 | 627 x350x200 | 627 x350x200 |
| Weight |
46Kg |
55Kg |
55Kg | 55Kg |
| BMS Protection Function |
Over charge protection, Over discharge protection, Temperature protection, Balanced function |
|||
| Charge-end-off Voltage |
43.8V |
58.4V |
58.4V | 58.4V |
| Max. Continuous Charging Current |
100A |
100A |
100A | 100A |
|
Max. Continuous Discharging Current |
180A |
180A |
180A | 180A |
|
Peak Discharge Current |
350A（3S） |
350A（3S) |
350A(3S) | 350A(3S) |
| Charge Temperature |
0-55℃ |
|||
| Discharge Temperature |
-20-55℃ |
|||
| Storage Temperature |
Within 2 months：-20℃~40℃，Within 6 months：-10-35℃ |
|||
| Waterproof Level |
IP67 |
|||
|
Optional |
Bluetooth/RS485 /CAN /Advanced Screen/Brake Module/Braking resistor/Heating film/Active Balancing Module |
|||
Features
1. Powerful performance with smooth acceleration and excellent hill-climbing and load-carrying capabilities
2. Exceptionally long cycle life, significantly reducing replacement costs
3. Lightweight body design for optimal vehicle load distribution
4. Built-in intelligent BMS management system with comprehensive safety features
5. Fast charging, durable, low self-discharge, and excellent range
6. Universal installation and easy replacement, compatible with mainstream golf cart models
Explore our comprehensive factory capabilities and customized solutions
Applications
Patrol Vehicles & Utility Vehicles
Golf Carts
FAQ
A: Sample orders start at 1 set, with small batches of 50 sets and large batches of 500 sets or more.We understand the various needs of partners with different scales.
A: Yes. Paid samples are available for evaluation and testing. Sample costs are refundable upon confirmation of a bulk order. Standard sample lead time is 7–10 business days.
A: Yes. We provide complete documentation packages, including UN38.3 test reports, MSDS, product specifications, and other relevant certification documents required for international shipping and customs clearance.
A: Yes. The battery is designed as a drop-in replacement with compatible dimensions and terminal configurations, eliminating the need for modifications to the vehicle's wiring or controller. It fits most mainstream golf cart brands and models, enabling fast installation and simplified inventory management.
A: Equipped with high-performance cells and an intelligent temperature-management BMS, the battery delivers stable power output in low-temperature conditions. It maintains reliable operation during cooler autumn and winter seasons with minimal impact on driving range and performance, making it suitable for golf courses across a wide range of climates.
A: Yes. We provide comprehensive OEM/ODM customization services, including battery specifications, connectors, communication protocols, and private-label branding. Every battery undergoes rigorous quality testing before shipment. We also offer a comprehensive warranty program and responsive technical support, helping distributors minimize after-sales service costs and maximize customer satisfaction.
A: Our standard warranty period is 3 years, with extended warranty options available for specific projects and volume orders. Please contact our sales team for details.
