Product Parameters
|
Model |
12V 100Ah |
12V 200Ah |
12V 230Ah |
12V 280Ah |
12V 314Ah |
12V 400Ah |
12V 560Ah |
12V 628Ah |
| Rated Voltage |
12.8V |
|||||||
|
Nominal Capacity |
100Ah |
200Ah |
230Ah |
280Ah |
314Ah |
400Ah |
560Ah |
628Ah |
| Energy | 1.28KWh | 2.56KWh | 2.944KWh | 3.584KWh | 4.019KWh | 5.12KWh | 7.168KWh | 8.038KWh |
| Size(mm) | 330x175x220 | 370x190x245 | 384*194*255 | 522x240x218 | 522x240x218 | 520*267*220 | 640x245x220 | 640*245*220 |
| Weight |
12.5 Kg |
20.5Kg |
23Kg |
26Kg |
32Kg |
40.5Kg | 50Kg |
52Kg |
| BMS Protection Function |
Over charge protection, Over discharge protection, Temperature protection, Balanced function |
|||||||
| Charge-end-off Voltage |
14.6V |
|||||||
| Max. Continuous Charging Current |
100A |
200A |
200A |
200A |
200A |
250A |
250A |
250A |
|
Max. Continuous Discharging Current |
200A |
200A |
200A |
200A |
200A |
300A |
300A |
300A |
|
Peak Discharge Current |
400A（3S） |
400A（3S) |
400A（3S) |
400A（3S) |
400A（3S) |
600A（3S） |
600A（S) |
600A（3S) |
| Charge Temperature |
0-55℃ |
|||||||
| Discharge Temperature |
-20-60℃ |
|||||||
| Storage Temperature |
Within 2 months：-20℃~40℃，Within 6 months：-10-35℃ |
|||||||
| Waterproof Level |
IP67 |
|||||||
|
Optional |
Bluetooth/CAN/RS485/Heating Function |
|||||||
Features
1. Built with premium lithium iron phosphate（ LiFePO₄）cells and housed in a waterproof, corrosion-resistant enclosure, specifically engineered to withstand harsh marine environments, including moisture, humidity, and salt spray exposure.
2. Equipped with a built-in intelligent BMS protection system that provides comprehensive protection against overcharging, over-discharging, short circuits, and extreme temperatures
3. Excellent deep-cycle performance supports frequent charging and discharging, ensuring a long service life.
4. Lightweight design significantly reduces weight compared to traditional lead-acid batteries, minimizing hull load.
5. Ultra-low self-discharge rate minimizes capacity loss during extended storage periods, making it ideal for seasonal and infrequently used vessels.
6. Supports flexible system expansion through series and parallel configurations, allowing customized capacity and voltage solutions for boats of various sizes and power requirements.
7. Compatible with multiple charging sources, including onboard generators, solar power systems, shore power, and DC charging systems.
8. Rugged, vibration-resistant construction ensures dependable performance and operational stability even in rough sea conditions.
Explore our comprehensive factory capabilities and customized solutions
Applications
1.Onboard House Power Systems / House Loads
2.Marine Navigation Equipment / Navigation & Electronics
3.Emergency Backup Power Systems
4.Marine Solar Energy Storage Systems
5.Dockside Power Supply / Shore Power Support During Berthing
FAQ
A: Yes. The battery features a sealed, corrosion-resistant design with excellent resistance to salt spray, moisture, and humidity, making it ideal for long-term marine applications and offshore operations.
A: Yes. In many applications, the battery can be installed as a drop-in replacement, reducing installation complexity and minimizing vessel downtime.
A: No. The battery is engineered with a rugged, vibration-resistant structure that maintains stable and reliable power output even in demanding marine environments and rough sea conditions.
A: The battery is compatible with multiple charging sources, including shore power chargers, onboard generators, and marine solar charging systems, providing flexible and convenient energy replenishment.
A: Thanks to its ultra-low self-discharge rate, the battery retains its charge exceptionally well during extended periods of inactivity, ensuring it is ready for use whenever needed.
