Product Parameters
|
Model |
24V 100Ah |
24V 200Ah |
24V 230Ah |
24V 280Ah |
24V 314Ah |
| Rated Voltage |
25.6V |
||||
|
Nominal Capacity |
100Ah |
200Ah |
230Ah |
280Ah |
314Ah |
| Energy | 2.56KWh | 5.12KWh | 5.888KWh | 7.168KWh | 8.038KWh |
| Size(mm) | 485x168x240 | 520x267x220 | 520x267x220 | 640x245x220 | 640x245x220 |
| Weight |
22Kg |
42.5Kg |
50Kg |
50Kg |
53Kg |
| BMS Protection Function |
Over charge protection, Over discharge protection, Temperature protection, Balanced function |
||||
| Charge-end-off Voltage |
29.2V |
||||
| Max. Continuous Charging Current |
100A |
200A |
200A |
200A |
200A |
|
Max. Continuous Discharging Current |
200A |
200A |
200A |
200A |
200A |
|
Peak Discharge Current |
300A（2S） |
300A（2S) |
300A（2S) |
300A（2S) |
300A（2S) |
| Charge Temperature |
0-55℃ |
||||
| Discharge Temperature |
-20-60℃ |
||||
| Storage Temperature |
Within 2 months：-20℃~40℃，Within 6 months：-10-35℃ |
||||
| Waterproof Level |
IP67 |
||||
|
Optional |
Bluetooth/CAN/RS485/Heating Function |
||||
Features
1. Designed with a standard 24V voltage across the entire series, these batteries are perfectly suited for RVs and campers. Simply replace the original lead-acid battery for immediate use.
2. Featuring high-quality lithium iron phosphate (LiFePO₄) cells, these batteries offer a long deep-cycle lifespan, stable and durable charging and discharging performance, and slow capacity degradation during long-term storage, resulting in a service life far exceeding that of traditional lead-acid batteries.
3. Built-in intelligent BMS protection system with multiple safeguards against overcharging, over-discharging, overcurrent, short circuits, and extreme temperatures, ensuring safer and more reliable power supply for RV travel.
4. Extremely low self-discharge rate ensures the battery retains its charge even during long-term vehicle storage, delivering excellent endurance for long-distance road trips and camping.
5. The lightweight design makes it lighter than lead-acid batteries of the same capacity, reducing vehicle weight without compromising the RV’s driving performance.
6. Supports series and parallel connection of multiple batteries for capacity expansion, and can be freely paired with inverters and solar panels to meet varying power usage requirements.
7. Compatible with multiple charging modes—including solar charging, onboard generators, and mains power—perfectly adapting to various RV charging scenarios.
Explore our comprehensive factory capabilities and customized solutions
Applications
Power Supply for Motorhome Camping
Provides power for interior lighting, electrical appliances, and kitchen and bathroom equipment, allowing you to live comfortably even when away from the mains supply
FAQ
A: Sample orders start at 1 set, with small batches of 50 sets and large batches of 500 sets or more. We understand the needs of partners of all sizes.
A: We accept payment for samples, and the sample fee will be refunded upon placement of a bulk order. Sample lead time is 7–10 days
A: Standard dimension and terminals support direct replacement, no complicated wiring changes required.
A: Supports multi-unit parallel connection to upgrade total capacity, matching various RV power needs.
A: Built-in BMS temperature protection ensures stable operation in hot and cold outdoor environments.
A: Compatible with solar panel, vehicle generator and shore power for flexible daily charging.
A: Durable lithium cells with full safety protection cut maintenance issues and replacement costs.
A: We provide a complete set of certified scanned copies and test report summaries, with UN 38.3 test reports and MSDS documents included for each batch.
